Pattern Characteristic
● Five broken line groove increased excellent drainage and operation the vertical safety.
● The main pattern groove of the small Rubber block effectively improve wheel Tire self-cleaning.
● Widen tread design increase travel distance.
Accepatable Tyre Position
Technical Specifications
| Tire Size | 12R22.5 | |
| Ply | 18 | |
| Load index | 152/149 | |
| Maximum load(kg) | Single tire | 3550 |
| Double tire | 3250 | |
| Corresponding air pressure(kpa) | Single tire | 930 |
| Double tire | 930 | |
| Measurement Wheel rim | 9.00 | |
| Allow using wheel rim | 8.25 | |
| Decorative pattern Depth(mm) | 20.5 | |
| New tire design size(mm) | Section width | 300 |
| Outer diameter | 1085 | |
