Pattern Characteristic
● The directional transverse block pattern effectively endows the tire with excellent driving and braking performance.
● The design of the ribs between the pattern blocks increases the strength of the root of the pattern block and prevents the root of the pattern block from tearing.
● The rubber protrusions at the bottom of the grooves effectively improve the self-cleaning performance of the tire.
Accepatable Tyre Position
Technical Specifications
| Tire Size | 13R22.5 | 315/80R22.5 | |
| Ply | 20 | 20 | |
| Load index | 156/153 | 156/150 | |
| Maximum load（kg) | Single tire | 4000 | 4000 |
| Double tire | 3650 | 3350 | |
| Corresponding air pressure(kpa) | Single tire | 930 | 860 |
| Double tire | 930 | 860 | |
| Measurement Wheel rim | 9.75 | 9.00 | |
| Allow using wheel rim | 9.00 | 9.75 | |
| Decorative pattern Depth(mm) | 20 | 20 | |
| New tire design size(mm) | Section width | 332 | 325 |
| Outer diameter | 1122 | 1079 | |
